Go big, do more
The 870 QVO is Samsung’s latest 2nd generation QLC SSD with up to 4TB of storage capacity. Dependable storage for PCs and laptops, with performance you can trust.
Enhanced in every way
With an expanded SATA interface limit of 560/530 MB/s sequential speeds, the 870 QVO improves random access speed and sustained performance. Intelligent TurboWrite accelerates write speeds and maintains long-term high performance with a larger variable buffer. 1 2 3 4
Boost capacity
The 870 QVO is available in 1, 2 and 4TB. Upgrade to the latest in SATA SSD technology to thrive in today’s digital world. 5 6 7
Reliable and sustainable
The capacity of the 1TB 870 QVO increases reliability up to 360 TBW (terabytes written) using a refined ECC (error-correcting code) algorithm for stable performance. Plus, it’s backed by a limited 3 year warranty* for ultimate peace of mind. 8 9 10
Upgrade with ease
Upgrading to 870 QVO is now easier than ever for anyone with a desktop PC or laptop that supports a standard 2.5-inch SATA form factor. Simply plug in the 870 QVO into a SATA slot and let the updated migration software take care of the rest.
Samsung Magician software
Keep your SSD in check with Samsung Magician 6.1 software. Manage your drive and enhance its performance with a wide range of useful tools to keep up with the latest updates and monitor the drive’s health and status.
World’s No.1 Flash Memory Brand
Experience the performance and reliability from the world’s number one brand for flash memory since 2003*. All firmware and components, including Samsung’s world-renowned DRAM and NAND, are produced in-house, allowing end-to-end integration for quality you can trust. 11
Specification
|
Collapse group heading
General Feature
|
||
|---|---|---|
| Product Type |
870 QVO SATA III 2.5″ SSD 1TB
|
 |
| Family Line |
870 QVO SATA III 2.5″ SSD
|
 |
| Capacity |
1TB
|
 |
| Interface |
SATA 6 Gbps Interface, compatible with SATA 3 Gbps & 1.5 Gbps interfaces
|
 |
| Compatibility |
Windows10/Windows 8/Windows 7/Windows Server 2003 (32 bit and 64 bit), Vista (SP1 and above), XP (SP2 and above), MAC OSX and Linux
|
 |
|
Collapse group heading
Performance
|
||
| Speed |
Read/write speeds of up to 560/530 MB/s
|
 |
| Encryption |
AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667)
|
 |
|
Collapse group heading
Type
|
||
| Product Type |
SATA SSD
|
 |
| Storage Type |
Internal
|
 |
| Interface |
SATA 6 Gb/s Interface
|
 |
| Read/Write Speeds |
up to 560/530 MB/s
|
 |
| Usage Application |
Client PCs
|
 |
|
Collapse group heading
Storage
|
||
| Capacity |
1TB
|
 |
|
Collapse group heading
Key Features
|
||
| Sequential Read Speed |
Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration
|
 |
| Sequential Write Speed |
Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
|
 |
| Compatibility |
Compatible with SATA 3 Gbps & 1.5 Gbps interfaces
|
 |
| Cache Memory |
Samsung 1 GB Low Power DDR4 SDRAM
|
 |
| Trim Support |
TRIM Supported
|
 |
| Security |
AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667)
|
 |
| S.M.A.R.T. Support |
S.M.A.R.T Supported
|
 |
| GC (Garbage Collection) |
Auto Garbage Collection Algorithm
|
 |
| WWN Support |
World Wide Name supported
|
 |
| Device Sleep Mode Support |
Yes
|
 |
| Internal Storage |
Samsung V-NAND 4bit MLC
|
 |
|
Collapse group heading
General
|
||
| Average Power Consumption (system level) |
Average: 2.2 W *Maximum: 4.0 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
|
 |
| Power consumption (Idle) |
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
|
 |
| Reliability (MTBF) |
1.5 Million Hours Reliability (MTBF)
|
 |
|
Collapse group heading
Environmental Specs
|
||
| Shock |
1,500 G & 0.5 ms (Half sine)
|
 |
|
Collapse group heading
Form Factor
|
||
| Product |
2.5 inch
|
 |
|
Collapse group heading
Dimensions (W x H x D)
|
||
| Product |
3.94″ X 2.76 ” X 0.27″
|
 |
|
Collapse group heading
Weight
|
||
| Product |
0.19 lbs.
|
 |
|
Collapse group heading
Warranty
|
||
| Product |
* Limited warranty up to 3 years or up to the TBW for each capacity ***For more information on the warranty, please visit www.samsung.com/support
|
 |
