Always Evolving SSD
The ultimate in performance, upgraded. Faster than the 970 EVO, the 970 EVO Plus is powered by the latest V-NAND technology and firmware optimization. It maximizes the potential of NVMe bandwidth for unbeatable computing. Comes in capacities of up to 1TB, with reliability of up to 600 TBW. 1
Level up Performance
The 970 EVO Plus reaches sequential read/write speeds up to 3,500/3,300 MB/s, up to 53% faster than the 970 EVO. Powered by the latest V-NAND technology—which brings greater NAND performance and higher power efficiency—along with optimized firmware, a proven in-house controller, and Intelligent TurboWrite boost speed. 2 3 4
Design Flexibility
The next advancement in NVMe SSDs. The 970 EVO Plus fits up to 1TB onto the compact M.2 (2280) form factor, greatly expanding storage capacity and saving space for other components. Samsung’s innovative technology empowers you with the capacity to do more and accomplish more.
Exceptional Endurance
The new standard in sustainable performance. Get up to 600 TBW with a 5-year limited warranty for lasting performance. The 970 EVO Plus provides exceptional endurance powered by the latest V-NAND technology and Samsung’s reputation for quality. 5 6 7
Unparalleled Reliability
Achieve a new level of drive confidence. Samsung’s advanced nickel-coated controller and heat spreader on the 970 EVO Plus enable superior heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to minimize performance drops.
Samsung Magician
Advanced drive management made simple. The Samsung Magician software will help you keep an eye on your drive. A suite of user-friendly tools helps keep your drive up to date, monitor drive health and speed, and even boost performance.
Specification
|
Collapse group heading
Type
|
||
|---|---|---|
| Product Type |
NVMe SSD
|
 |
| Storage Type |
Internal
|
 |
| Interface |
PCIe Gen 3.0 x 4, NVMe 1.3
|
 |
| Read/Write Speeds |
3,500/3,200 MB/s
|
 |
| Usage Application |
Client PCs
|
 |
| Series |
970 EVO Plus
|
 |
|
Collapse group heading
Application
|
||
| Consumer |
Yes
|
 |
|
Collapse group heading
Storage
|
||
| Capacity |
500GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
|
 |
|
Collapse group heading
Key Features
|
||
| Sequential Read Speed |
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
|
 |
| Sequential Write Speed |
Up to 3,200 MB/s * Performance may vary based on system hardware & configuration
|
 |
| Random Read Speed |
Random Read (4KB, QD32): Up to 480,000 IOPS; Random Read (4KB, QD1): Up to 19,000 IOPS * Performance may vary based on system hardware & configuration
|
 |
| Random Write Speed |
Random Write (4KB, QD32): Up to 550,000 IOPS; Random Write (4KB, QD1): Up to 60,000 IOPS * Performance may vary based on system hardware & configuration
|
 |
| Controller |
In-house
|
 |
| NAND Flash |
Samsung V-NAND 3-bit MLC
|
 |
| Cache Memory |
Samsung 512MB Low Power DDR4 SDRAM
|
 |
| Trim Support |
Supported
|
 |
| AES Encryption |
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
|
 |
| Security |
AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667)
|
 |
| S.M.A.R.T. Support |
Supported
|
 |
| GC (Garbage Collection) |
Auto Garbage Collection Algorithm
|
 |
| WWN Support |
Not supported
|
 |
| Device Sleep Mode Support |
Yes
|
 |
| Internal Storage |
Samsung V-NAND 3-bit MLC
|
 |
| Temperature proof |
Yes
|
 |
| NVMe |
Yes
|
 |
| Gaming SSDs |
Yes
|
 |
|
Collapse group heading
General
|
||
| Average Power Consumption (system level) |
* Average: 5.8 W * Maximum: 9 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
|
 |
| Power consumption (Idle) |
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
|
 |
| Voltage |
3.3 V ± 5 % Allowable voltage
|
 |
| Reliability (MTBF) |
1.5 Million Hours Reliability (MTBF)
|
 |
|
Collapse group heading
Environmental Specs
|
||
| Operating Temperature |
0 – 70 ℃ Operating Temperature
|
 |
| Shock |
1,500 G & 0.5 ms (Half sine)
|
 |
|
Collapse group heading
Form Factor
|
||
| Product |
M.2 (2280)
|
 |
|
Collapse group heading
Dimensions (W x H x D)
|
||
| Product |
3.16″ x 0.87″ x 0.09″
|
 |
|
Collapse group heading
Weight
|
||
| Product |
0.3 oz.
|
 |
|
Collapse group heading
Software
|
||
| Management SW |
Magician Software for SSD management
|
 |
|
Collapse group heading
Warranty
|
||
| Product |
5-Year Limited Warranty or: 300 TBW Limited Warranty
|
|
Categories: PC Components, Samsung, SATA/NVMe SSD
