Upgrade to impressive NVMe® speed
Harness your PC’s potential with the 980. Whether you need a boost for gaming or a seamless workflow for heavy graphics, the 980 is a smart choice for outstanding SSD performance — and it’s all backed by an NVMe* interface and PCIe 3.0 technology. 1
Packed with speed
Satisfy your need for speed with PCIe 3.0, using HMB technology and NVMe interface for high efficiency. The 980 delivers value, without sacrificing sequential read/write speeds up to 3,500/3,000 MB/s*, over 6.2x the speed of SATA SSDs**. 2 3 4
Keep moving with Full Power Mode
Keep your SSD running at its peak with Full Power Mode, which drives continuous and consistent high performance. Enable through Samsung Magician software to keep your SSD in active mode with no latency, so you can instantly jump back into large intensive work files or graphics-heavy games.
Built for the long run
Keep your files safe with an SSD that’s in it for the long haul. With up to 600 TBW* and a 5-year limited warranty, the 980’s optimized endurance comes with trusted reliability thanks to Samsung’s in-house solutions, from the advanced controller to V-NAND and the latest firmware. 5 6 7
Reliable thermal control
High-performance SSDs usually require high-performance thermal control. To ensure stable performance, the 980 uses nickel coating to help manage the controller’s heat level and a heat spreader label to deliver effective thermal control of the NAND chip.
Smart thermal solution
Embedded with Samsung’s cutting-edge thermal control algorithm, 980 manages heat on its own to deliver durable and reliable performance, while minimizing performance fluctuations during extended usage.
Samsung Magician software
Unlock the full potential of 980 with Samsung Magician’s advanced, yet intuitive optimization tools. Monitor drive health, optimize performance, protect valuable data, and receive important updates with Magician to ensure you’re always getting the best performance out of your SSD.
World’s No.1 Flash Memory Brand
Experience the performance and reliability that you can only get from the world’s number one brand for flash memory since 2003*. All firmware and components, including Samsung’s world-renowned DRAM and NAND, are produced in-house, allowing end-to-end integration for quality you can trust. 8
Specification
|
Collapse group heading
General Feature
|
||
|---|---|---|
| Product Type |
980 PCIe® 3.0 NVMe® SSD 1TB
|
|
| Family Line |
980 PCIe® 3.0 NVMe® SSD
|
|
| Capacity |
1TB
|
|
| Interface |
PCIe® Gen 3.0 x4, NVMe® 1.4
|
|
| Dimension (WxHxD) |
80.15 x 2.38 x 22.15 (mm)
|
|
|
Collapse group heading
Performance
|
||
| Speed |
Read/write speeds up to: 3,500/3,000MB/s
|
|
| Encryption |
AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667)
|
|
|
Collapse group heading
Type
|
||
| Interface |
PCIe® Gen 3.0 x4, NVMe 1.4
|
|
| Usage Application |
Client PCs
|
|
|
Collapse group heading
Storage
|
||
| Capacity |
1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
|
|
|
Collapse group heading
Key Features
|
||
| Sequential Read Speed |
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
|
|
| Sequential Write Speed |
Up to 3,000 MB/s * Performance may vary based on system hardware & configuration
|
|
| Cache Memory |
HMB(Host Memory Buffer)
|
|
| Trim Support |
Supported
|
|
| S.M.A.R.T. Support |
Supported
|
|
| GC (Garbage Collection) |
Auto Garbage Collection Algorithm
|
|
| WWN Support |
Not supported
|
|
| Device Sleep Mode Support |
Yes
|
|
| Internal Storage |
Samsung V-NAND 3-bit MLC
|
|
| NVMe |
PCIe® 3.0
|
|
|
Collapse group heading
General
|
||
| Average Power Consumption (system level) |
*Average: 4.6 W* Actual power consumption may vary depending on system hardware & configuration
|
|
| Power consumption (Idle) |
Max. 45 mW * Actual power consumption may vary depending on system hardware & configuration
|
|
| Reliability (MTBF) |
1.5 Million Hours Reliability (MTBF)
|
|
|
Collapse group heading
Environmental Specs
|
||
| Shock |
1,500 G & 0.5 ms (Half sine)
|
|
|
Collapse group heading
Form Factor
|
||
| Product |
M.2 2280
|
|
|
Collapse group heading
Warranty
|
||
| Product |
* Limited warranty up to 5 years or up to the TBW for each capacity ***For more information on the warranty, please visit www.samsung.com/support
|
|
